Practically all server applications require some sort of synchronization between multiple threads. Most of the synchronization work is done for us at the framework level, such as by our web server, DB client or messaging framework. Java and Scala provide a multitude of components to write solid multi-threaded applications. These include object pools, concurrent collections, advanced locks, execution contexts etc..

To better understand these, let’s explore the most synchronization idiom – the Object lock. This mechanism powers the synchronized keyword, making it one of, if not the most popular multi-threading idiom in Java. It is also at the base of many of the more complex patterns we use such as thread and connection pools, concurrent collections and more.

The synchronized keyword is used in two primary contexts:

• As a method modifier to mark a method that it can only be executed by one thread at a time.
• By declaring a code block as a critical section – one that’s only available to a single thread at any given point in time.

Locking Instructions

Fact #1

Synchronized code blocks are implemented using two dedicated bytecode instructions, which are part of the official specification – MonitorEnter and MonitorExit. This differs from other locking mechanisms, such as those found in the java.util.concurrent package, which are implemented (in the case of HotSpot) using a combination of Java code and native calls made through sun.misc.Unsafe.

These instructions operate on an object specified explicitly by the developer in the context of the synchronized block. For synchronized methods the lock is automatically selected to be the “this” variable. For static methods the lock will be placed on the Class object.

Synchronized methods can sometimes cause bad behavior. One example is creating implicit dependencies between different synchronized methods of the same object, as they share the same lock. A worse scenario is declaring synchronized methods in a base class (which might even be a 3rd party class) and then adding new synchronized methods to a derived class. This creates implicit synchronization dependencies across the hierarchy and has the potential of creating throughput issues or even deadlocks. To avoid these, it’s recommended to use a privately held object as a lock to prevent accidental sharing or escapement of locks.

[adrotate group=”11″]

The Compiler and Synchronization

There are two bytecode instructions responsible for synchronization. This is unusual, as most bytecode instructions are independent of each other, usually “communicating” with one another by placing values on the thread’s operand stack. The object to lock is also loaded from the operand stack, previously placed there by either dereferencing a variable, field or invoking a method returning an object.

Fact #2

So what happens if one of the two instructions is called without a respective call to the other? The Java compiler will not produce code that calls MonitorExit without calling MonitorEnter. Even so, from the JVM’s perspective such code is totally valid. The result of such a case would be that the MonitorExit instruction with throw an IllegalMonitorStateException.

A more dangerous case is what would happen if a lock is acquired via MonitorEnter, but isn’t released via a corresponding call to a MonitorExit. In this case the thread owning the lock can cause other threads who are trying to obtain the lock to block indefinitely. It’s worth noting that since the lock is reentrant, the thread owning the lock may continue to happily execute even if it were to reach and reenter the same lock again.

And here’s the catch. To prevent this from happening, the Java compiler generates matching enter and exit instructions in such a way that once execution has entered into a synchronized block or method, it must pass through a matching MonitorExit instruction for the same object. One thing that can throw a wrench into this, is if an exception is thrown within the critical section.

[java]
public void hello() {
synchronized(this) {
System.out.println(“Hi!, I’m alone here”);
}
}
[/java]

Let’s analyze the bytecode –

[java]
aload_0 //load this into the operand stack
dup //load it again
astore_1 //backup this into an implicit variable stored at register 1
monitorenter //pop the value of this from the stack to enter the monitor
//the actual critical section
getstatic java/lang/System/out Ljava/io/PrintStream;
ldc “Hi!, I’m alone here”
invokevirtual java/io/PrintStream/println(Ljava/lang/String;)V
aload_1 //load the backup of this
monitorexit //pop up the var and exit the monitor
goto 14 // completed – jump to the end
// the added catch clause – we got here if an exception was thrown –
aload_1 // load the backup var.
monitorexit //exit the monitor
athrow // rethrow the exception object, loaded into the operand stack
return
[/java]

The mechanism used by the compiler to prevent the stack from unwinding without going through the MonitorExit instruction is pretty straightforward – the compiler adds an implicit try…catch clause to release the lock and rethrow the exception.

Fact #3

Another question is where is the reference to the locked object stored between the corresponding enter and exit calls. Keep in mind that multiple threads could be executing the same synchronized block concurrently, using different lock objects. If the locked object is the result of a method being invoked, it’s highly unlikely the JVM will execute it again, as it may change the object’s state, or may not even return the same object. The same can be true for a variable or field which might have changed since the monitor was entered.

The monitor variable. To counter this, the compiler adds an implicit local variable to the method to hold the value of the locked object. This is a smart solution, as it imposes fairly minimal overhead on maintaining a reference to the locked object, as opposed to using a concurrent heap structure to map locked objects to threads (a structure which in itself might need synchronization). I first observed this new variable when building OverOps‘s stack analysis algorithm and saw there were unexpected variables popping up in the code.

Notice that all this work is done at the Java compiler level. The JVM is perfectly happy to enter a critical section through a MonitorEnter instruction without exiting it (or vice versa), or use different objects for what should be corresponding enter and exit methods.

Locking at the JVM Level

Let’s take a deeper look now into how locks are actually implemented at the JVM level. For this we’ll be examining the HotSpot SE 7 implementation, as this is VM specific. Since locking can have some pretty adverse implications on code throughput, the JVM has put in place some very strong optimizations to make acquiring and releasing locks as efficient as possible.

Fact #4. One of the strongest mechanisms put in place by the JVM is thread lock biasing. Locking is an intrinsic capability each Java objects has, much like having a system hashcode or a reference to its defining class. This is true regardless of the object’s type (you can even use a primitive array as a lock if you’d like).

These types of data are stored in each object’s header (also known as the object’s mark). Some of this data that is placed in the object’s header is reserved for describing the object’s locking state. This includes bit flags describing the object’s locking state (i.e. locked / unlocked) and a reference to the thread which currently owns the lock – the thread towards the object is biased.

In order to conserve space within the object header, Java thread objects are allocated in a lower segment of the VM’s heap in order to reduce the address size and save up on bits within each object’s header (54 or 23 bits for 64 and 32 bit JVMs respectively).

The Locking Algorithm

When the JVM attempts to acquire a lock on an object it goes through a series of steps ranging from optimistic to the pessimistic.

Fact #5

A lock is acquired by a thread if it succeeds in establishing itself as the object lock’s owner. This is determined by whether the thread is able to install a reference to itself (a pointer to the internal JavaThread object) in the object’s header.

A first attempt to do this is done using a simple compare-and-exchange (CAS) operation. This is very efficient as it can usually translate into a direct CPU instruction (e.g cmpxchg). CAS operations along with an OS specific thread parking routines serve as the building blocks for the object synchronization idiom.

If the lock is either free or has been previously biased toward this thread the lock on the object is obtained for the thread and execution can continue immediately. If the CAS fails the JVM will perform one round of spin locking where the thread parks to effectively put it to sleep between retrying the CAS. If these initial attempts fail (signaling a fairly higher level of contention for the lock) the thread will move itself to a blocked state and enqueue itself in the list of threads vying for the lock and begin a series of spinlocks.

Releasing the lock. When exiting the critical section through a MonitorExit instruction, the owner thread will try to see if it can wake any of the parked threads which may be waiting for the lock to be released. This process is known as choosing an “heir”. This is meant to increase liveliness, and to prevent a scenario where threads remain parked while the lock has already been released (also known as stranding).

Debugging server multi-threading problems is hard, as they tend to depend on very specific timing and OS heuristics. It was one of the reasons that got us working on OverOps in the first place.

This one is going to be a bit scary. After all, we’re dealing with a deadly killer here. And some nasty log files. So hold on tight to your seats! We’re going to cover immediate and actionable advice for stopping swallowed exceptions once and for all.

In this post, our goal is to see what it takes to avoid the risks of mishandled errors, and we’re going to do this by understanding the negative impact of swallowed exceptions, and learning how to fix them.

We’re going to investigate and find the silent killer of Java applications. Hopefully, we’ll also have fun while doing it!

The time has come to figure it out.

Release-Day Anxiety

This scenario might feel familiar. Unfortunately.

New errors keep appearing on release day, and you’re trying to deal with them as fast as you can.

The investigation has begun and the clock is ticking. Launch days induce anxiety for a reason. We hope at least this wasn’t a Friday. 5 PM on a Friday.

Let’s say we know there’s something wrong with our application because we received a lot of complaints from our users, or some business metric is trending down, and now we need to investigate what happened. Here’s a recent example of how this might look like when a reliability story hits the news.

We’ll need to look at massive amounts of unstructured data, trying to understand the story that this log file hides from us, and it’s probably going to be a tedious manual process. In this particular example, we’re looking at a file with DEBUG and INFO-level statements in it. But more often than not, in production, we’ll only have WARN and above turned on. In fact, we found that about ⅔ of the log data is deactivated in production, you can read more about it right here.

Even if you’re using a log management tool without relying on grepping your way through the console, it’s basically the same log data in a fancier interface.

And this is especially painful when it comes to knowing there’s a problem, before a significant portion of end users is negatively impacted. There is just too much noise out there to have an understanding of what’s important.

After the initial digging in the log file, we see that something just doesn’t feel right. No clues yet. Seems more like guesswork at this point.

What’s more stressful than looking for the root cause of a production error in a noisy log file? Not too many things. Well, maybe one thing can make this whole scenario even worse.

What if… The error we’re looking for, is not even in the logs?

The silent killer we’re trying to capture got away and left no clues in the logs. But we still need to figure out what might have caused this.

“Could Not Reproduce” is not an answer we can accept. Not when it means hurting customers and losing revenue.

There must be a better way to solve this. Back to the drawing board.

Now that we’ve seen what’s the negative impact of hidden errors, let’s see how it connects back to exceptions. To dig in, we wanted to take a closer look at what developers do in exception catch blocks. We looked at a recent research paper from the University of Waterloo that used Github’s massive Java dataset to investigate that exact question:

“Analysis of Exception Handling Patterns in Java Projects: An Empirical Study”, the original research can be accessed right here, and we’ve also published an analysis to review the results that you can quickly read through to get the gist.

The research looked at over half a million Java projects that included 16M catch blocks and segmented these into groups.

What Do Developers Do In Exception Catch Blocks?

We see that it basically splits into 3 groups:

1. Documenting what happened, through logging, printing a stack trace or printing out information to the console.
2. Rethrowing an exception, probably a wider abstraction that one of the methods further up the call stack would know how to handle.
3. And….. Unfortunately…. Nothing. An empty block. Swallowing the exception without any trace. And looks like it even happens at least as often as logging it. That’s… quite alarming to say the least.

Boom! Busted. Swallowed exceptions are a major factor that’s causing errors to go unnoticed. We found our killer.

Instead of doing the right thing by documenting exceptions with a logged error or warning, sometimes developers choose to ignore them. This could happen either because they’re thinking that it wouldn’t happen, or just ignoring it altogether trying to suppress and hide it.

As a quick recap of what we’ve covered so far, we’ve seen that:

• Troubleshooting errors in unforeseen conditions is extremely hard with a severe impact on users.
• Approximately 20% of errors never make it to the logs.
• Swallowed exceptions are caught in empty catch blocks.

What Should Change Going Forward?

Now that we understand the negative impact of swallowed exceptions, let’s talk about what needs to be done to address them.

1. Code Review Guidelines

Basics first. It might be time to refresh some code review guidelines. Make sure there are no empty catch blocks in future deployments, there’s no excuse for neglecting proper exception handling.

2. Logging Refactor

This one might be a bit tougher and easier said than done since it would mean taking a deep dive into legacy code. Updating existing code to include meaningful logging statements, and trying to figure out what those empty catch blocks might mean.

One way to enforce these 2 solutions and uncover all empty catch blocks is to make sure code-style inspections are turned on in your IDE. Here’s what it looks like in IntelliJ:

Settings -> Inspections -> Error handling -> Empty ‘catch’ block

3. Continuous Reliability

Another approach that we use ourselves, is to implement Continuous Reliability and automate root cause analysis. Swallowed exceptions or not, there are so many error conditions out there that it’s impossible to predict them all, let alone know which data to log to be able to troubleshoot them in the future.

We need to be more agile than ever, and it doesn’t mean that we can be flexible about error-prone code running loose in production. To see how it works in production and pre-production environments, try it out for yourself or request a demo with one of our solutions experts.

Final Thoughts

It’s 2018. Let’s make swallowed exceptions a thing of the past. No more empty catch blocks, and no more unknown errors. Does the scenario we described sounds familiar? Did you have other experiences with swallowed exceptions? Let us know in the comments section below!
